Main Features
1、3.7V Rechargeable Lithium Battery
2、Frequency Range：UHF 420-450MHZ
3、Wide/Narrow Band Selection:25KHz/12.5KHz
4、Programmable by PC
5、Output power：2W/05W
6、50 Groups CTCSS，105 Groups DCS
7、Up to 99 Channels(1-99)
8、Time-out timer(TOT)
9、VOX Level: OFF/1/2/3/4/5
10、Busy Channel Lockout (BCLO)
11、Squelch Level:0-9
12、Battery Saving Function
13、Monitor Function
14、Low Battery Voltage Warning/Indication
15、Chinese/English Language

General
Frequency range 420-450MHz
Memory channels 99
Operation voltage DC3.7V（li-ion Battery）
Frequency stability ±2.5ppm
Operation temperature -20℃~+50℃
Mode of operation Simplex
Antenna impedance 50Ω
Ground connection Negative electrode
Volume 58x28.5x172MM

Transmitter
RF Power 2W/0.5W
Modulation FM
Max frequency deviation ≤±5KHz
Stray Radiation ≤-60dB
Transmit current ≤1000mA
Pre-emphasis Character 6dB/per octave

Receiver
Sensitivity <0.16uv (12dB SINAD)
Squelch Sensitivity < 0.2uv
Audio power ≥380mW
Audio distortion <10%
Intermodulation ≥65dB
Receive current ≤380mA

Standard Package Content
Walkie talkie
Li-Ion battery
Belt Clip
User's Manual
Charger
　

Download
T12_Users_Manual1567587364888
Programming Software
